MPP Solar PIP-1012LV-MS / 1,000W Output / All In One Solar Inverter/Charger/Controller
Roll over image to zoom in
Specifications
- Operating/Storage Temp.: 0°C~55°C / -15°C~60°C
- Operating Humidity: 20~90%RH Non-Condensing
- Dimension: 355 x 272 x 100mm
- Net Weight: 6.5kg
120vac 1000W 12V off-grid solar inverter + mppt solar charger 40A, (PV input 102Vdc) + battery charger 20A
- 110V / 120V adjustable output design
- 40A / 500W MPPT charger
- 50Hz & 60Hz support
- Selectable AC input volt range based on load type
- Programmable parameters
- Adjustable bulk & float charging voltage
- Genset starter dry contact
- FREE monitoring software
- LCD Display + LED indicators
Electrical Specifications
- Max Continuous Power: 1000W
- Parallel Capability: None
- Input Voltage Range: 65~140VAC (Appliance mode), 95~140VAC (UPS Mode)
- Input/Output Frequency: 50Hz/60Hz Auto sensing
- Output Voltage: 110/120VAC±5% user selectable
- Output waveform: Pure Sine Wave
- Peak Efficiency: 90%
- Nominal DC Voltage: 12V
- Max DC Voltage (battery): 15.5V
- Transfer Time: <10ms (UPS mode), <20ms (Appliance Mode)
- Charging Mode: 3-stage
- AC Recharging Current: 20A
- No Load Power Consumption: <15W
- Power Saving Mode: <5W
Solar Charger
- Algorithm: MPPT
- Max PV Input/Output: 500W
- Max Charging Current: 40A
- Max PV Input Voc: 102V
- MPPT Range: 15V-80V
- Standby power: 2W
